SPECIFICATION
Application
Cleanroom supply and return air
Filter Classification
E11-U16
Type
EPA-HEPA and ULPA panel with a gasket seal for 100% air tightness
Nominal Airflow (m/s)
0.45
Media
Waterproof micro glass fibres
Air Volume (m³/hr)
See data sheet
Gasket
2 component polyurethane Gel
Initial Pressure drop (Pa)
See data sheet
Separator
Thermoplastic hotmelt
Temperature (max)
70 ºC in continuous operation
Filter test
Conform EN1822; NEN-EN-ISO 29463
Frame
Extruded anodized alumunium
Faceguard
Mild steel epoxy coated
